RM MSC10500M
Tracked Incline Screen
Meet us at BAUMA 2025 in Munich - Get your tickets now!
Highest Performance on Tracks
The RM MSC10500M incline screen features a large 22' x 5' screen-box for unrivalled throughput. Available in 2 and 3 deck configurations. It is ideal for high production capacities in soil, coal, crushed stone, millings, sand & gravel applications. User benefits include a quick set-up time, drop down tail conveyor and mesh-screen access system to aid screen media changes.
Large Feed Hopper
Easy to feed with wide loader buckets.
Tipping Grid
Radio remote controlled tipping grid.
Easy to Change Screens
Lower screen-box and conveyors for ease of access.
Optional Rinser-Kit
The RM MSC10500M can be converted into a mobile wet screening plant for washing sand and gravel. The rinser-kit includes plumbing, spray bars, a catch box, and fittings for an after-treatment system.
Applications
2 Deck RM MSC10500M Specs
| Capacity | 450 tph 500 TPH |
| Screen-box | 6,700 x 1,525 mm 5 x 22 ft |
| Screen-decks | 2 2 |
| Screen angle | 20 - 30° 20 - 30° |
| Feed unit | 9.2 m³ 12 yd³ |
| Engine | 97 kW 130 HP |
| Drive | Diesel-hydraulic Diesel-hydraulic |
| Transport dimension | 18,850 x 3,000 x 3,400 mm 61'10" x 9'10" x 11'2" |
| Weight | 36,000 kg 79,400 lbs |
3 Deck RM MSC10500M Specs
| Capacity | 450 tph 500 TPH |
| Screen-box | 6,700 x 1,525 mm 5 x 22 ft |
| Screen-decks | 3 3 |
| Screen angle | 20 - 30° 20 - 30° |
| Feed unit | 9.2 m³ 12 yd³ |
| Engine | 97 kW 130 HP |
| Drive | Diesel-hydraulic Diesel-hydraulic |
| Transport dimension | 18,860 x 3,000 x 3,500 mm 61'11" x 9'10" x 11'6" |
| Weight | 37,500 kg 82,700 lbs |
